Kraft paper machine -- suppliers and manufacturers in China two wires two floor paper making machine
Technical specification
Technical parameters are design base of kraft paper machine each section and auxiliary equipment. Each section and auxiliary equipment of this kraft paper machine will strictly access according to the following parameters:
Item | Parameters |
Main output | Kraft paper |
GSM | 100-150g/m2 |
Net paper width | 3600mm |
Working speed | 150-200m/min. |
Design speed | 250m/min. |
Crawling speed | 25m/min. |
Dynamic balance speed | 200m/min. |
Headbox width | 3950mm |
Gauge | 4700mm |
Description of wire section
The wire section of kraft paper machine is composed of wire table frame, breast roll and lifting device, de-watering element group, wire guide roll, doctor, high/low pressure spray pipe, edge sprayer pipe, tensioner, corrector, white water pan, wire drive roll, vacuum couch roll, deckle needle, paper leading needle and vacuum pipelines etc. Wire section all transmission part corrects dynamic balance. Paper dryness after wire section reaches 20-22%. Adopts cantilever screen changing mold. Wire tension is calculated as 7KN/M. All rolls in wire section adopt grease lubrication.
FAQ:
1. How to install and maintain the machine?
A: Firstly,we will provide the installation guild with the machine for your reference.
Secondly,our company is responsible for training production workers for you, ensuring that the workers will be independent operation.
2. How can we get the matching accessories or wearing parts conveniently?
A: During the warranty,Our company can replace the accessories for free .Out of warranty,we can provide them at the preferable price .In fact,the wearing parts are standard parts that you could get it in your country at your convenience.
