Cost-Effective Yankee Dryer
Description
Yankee dryer
Dryer cylinder
Paper product making machinery dryer section
Yankee dryer cylinder
Material is cast iron.
Inner side grooved for Yankee dryer.
Advantages of our dryer cylinder
1. Improves the drying ability. |
2. Improves the water distribution of paper sheet. |
3. Saves energy and reduces the energy loss. |
4. Easy to install. |
5. Improves the uniformity of dryer cylinder surface temperature. |
6. Reduces paper break. |
7. Reduces the inlet steam pressure of dryer cylinder. |
Main specifications
Diameter | Material | Design pressureHardness | Face length | Working speed | Roughness | Hardness |
Dia3000mm | HT300-HT350 | 0.3-1.1MPa | 1450-8000mm | 500-1200m/min | 0.1-0.4Ra | HB230-260 |
Dia3660mm | HT300-HT350 | 0.3-1.1MPa | 1450-8000mm | 500-1200m/min | 0.1-0.4Ra | HB230-260 |
Dia3800mm | HT300-HT350 | 0.3-1.1MPa | 1450-8000mm | 500-1200m/min | 0.1-0.4Ra | HB230-260 |
