Coated Duplex Board Paper Making Machine With PLC Control

Coated Duplex Board Paper Making Machine With PLC Control

  • High Light

    Duplex Board Paper Making Machine


    Coated Board Paper Making Machine


    PLC Paper Board Making Machine

  • Item
    Coated Duplex Board Paper Making Machine
  • Machine Type
    4 Wires Paper Making Machine
  • Wire Width
  • Paper Type
    Coated Duplex Board
  • Paper Basic Weight
  • Design Speed
  • Final Paper Width
  • Place of Origin
    Henan, China
  • Brand Name
  • Certification
  • Model Number
  • Minimum Order Quantity
  • Price
  • Packaging Details
    wooden case
  • Delivery Time
  • Payment Terms
    T/T, L/C
  • Supply Ability

Coated Duplex Board Paper Making Machine With PLC Control

Coated duplex board paper making machine



This 4 wires paper making machine are designed and produced by our company specially to produce coated duplex board paper. It can produce paper of 180-400g/m2. High quality two sides coating.


This machine is composed of 4ply wire forming section, top wire forming section, pressing section, dryer section, sizing section, transmission section, coating section, base section, steam hood, pope reel and so on.


This coated duplex board paper making machines adopts 4ply wires with top former. It's equiped with high level and famous brand air cushion headbox.


Configuration of air cushion headbox

Max. flow speed 300m/min
Mini flow speed 140m/min
Over flow 2-5%
Control system PLC
Pressure measuring system pressure sensor, pressure control valve
Liquid level measuring system Liquid level sensor, hydraulic control electric valve
Decoupler controller, computer, display screen


Equipment gurantee period


Quality assurance time for all mechanical equipment of this machine: 12 months after normal operation; bearing and cots quality assurance time: 6 months after normal operation. During the quality assurance time, any equipment quality accidents caused by non-operational errors shall be the responsibility of the supplier. Shaft fracture warranty for 3 years.


The warranty period begins from the normal operation date of the paper machine. If there is a failure during the warranty period, the supplier personnel will deal with it in a timely manner. When submitting the equipment, the supplier will provide the general assembly drawing, basic drawing, transmission drawing and so on of the paper machine. After the completion of the project, if there are any changes, and then provide the corresponding change documents.


Coated Duplex Board Paper Making Machine With PLC Control 0
